HD130
Operating Weight
15.3 ton
Emission
STAGE V
Rated Power
155 hp / 2,200 rpm
Blade Width
3,370 mm
Specifications
General
Blade Length
3,370 mm
Bucket Capacity
4.18 m³
Operating Weight
15.3 ton
Rated Power
155 hp / 2200 rpm
Engine
Emission
STAGE V
Max. Torque
72.399 kgf·m / 1,400 rpm
Engine Model
Perkins 1204J
Hydraulic System
Type
VARIABLE PISTON
System Pressure
270 kgf/cm²
Implement Maximum Flow Rate
132 ℓ/min
Tank Capacity
Fuel Tank
267 ℓ
Engine Oil
12.4 ℓ
Hydraulic Tank
100 ℓ
Dimensions
Blade Width
3,370 mm
Digging Depth
405 mm
Overall Height
3,180 mm
Overall Length
5,040 mm
Ground Clearance
355 mm
Maximum Blade Angle
25 deg
Overall Track Length
3,690 mm
- -These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog.
- -The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
