HDT105
Operating Weight
35 ton
Rated Payload
70 ton
Emission
TIER 3
Rated Power
530 hp / 2,100 rpm
Specifications
General
Heaped
43 m³
Rated Payload
70 ton
Operating Weight
35 ton
Rated Power
530 hp / 2100 rpm
Engine
Emission
TIER 3
Max. Torque
234.5 kgf·m
Engine Model
Weichai 530 horse power
Hydraulic System
Implement Circuit
230 kgf/cm²
Main Pumps Rated Flow
250 ℓ/min
Tank Capacity
Fuel Tank
600 ℓ
Engine Oil
27 ℓ
Hydraulic Tank
200 ℓ
Performance
Travel Speed (forward, Maximum)
40 km/h
Travel Speed (reverse, Maximum)
7 km/h
Dimensions
Overall Width
3,130 mm
Overall Height
4,160 mm
Overall Length
9,360 mm
Inner Turning Radius
8,400 mm
Outer Turning Radius
11,000 mm
- -These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog.
- -The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
