HSL850-7A
Type
-
Rated Operating Capacity
-
Emission
TIER 3
Rated Power
74.3 hp / 2,400 rpm
Lift Arm Path
Radial Lift Path
Specifications
General
Bucket Capacity
0.37 m³
Operating Weight
3.36 ton
Rated Operating Capacity
860 kg
Rated Power
74.3 hp / 2400 rpm
Engine
Emission
TIER 3
Max. Torque
27 kgf·m / 1,500 rpm
Engine Model
Kubota V3307-T
Hydraulic System
Hydraulic Flow Rate
63.9 ℓ/min
Hydraulic Pressure
175 kgf/cm²
Hydraulic Flow Rate (high-Flow)
110 ℓ/min
Hydraulic Pressure High Flow
150 kgf/cm²
Tank Capacity
Fuel Tank
83 ℓ
Hydraulic Tank
57 ℓ
Performance
Lift Arm Path
Radial Lift Path
Tipping Load
1,720 kg
Dimensions
Wheelbase
1,100 mm
Overall Width
1,890 mm
Overall Height
2,000 mm
Overall Length
3,470 mm
Ground Clearance
205 mm
Operating Range
Max. Dumping Height
2,410 mm
Reach At Maximum Lift
510 mm
Hinge Pin Height At Maximum Lift
3,080 mm
Tire
Rear Tires STD
12/16.5-12
Front Tires STD
12/16.5-12
Power Train Undercarriage
Tires Type
12/16.5-12
Travel Speed (1, Speed)
11.4 km/h
- -These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog.
- -The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
