HX260FC
Type
Others
Operating Weight
32.9 ton
Emission
TIER 3
Rated Power
190 hp / 2,200 rpm
Specifications
General
Operating Weight
32.9 ton
Rated Power
190 hp / 2200 rpm
Engine
Emission
TIER 3
Max. Torque
94.7 kgf·m / 1,400 rpm
Engine Model
HYUNDAI / HE6.7
Hydraulic System
Type
Others
Implement Circuit
350 kgf/cm²
Main Pumps Rated Flow
2x247 ℓ/min
Tank Capacity
Fuel Tank
450 ℓ
Hydraulic Tank
160 ℓ
Performance
Swing Speed
10.9 rpm
Travel Speed
5.6 km/h
Max. Gradeability
35 deg
Max. Traction Force
22,200 kgf
Dimensions
Overall Width
3,470 mm
Overall Height
3,390 mm
Overall Length
10,100 mm
Ground Clearance
765 mm
Tail Swing Radius
3,090 mm
Tumbler Distance
4,030 mm
Operating Range
Arm Length
3,050 mm
Boom Length
5,850 mm
Min. Swing Radius
3,450 mm
Max. Digging Depth
3,890 mm
Max. Digging Reach
8,740 mm
Max. Digging Height
9,610 mm
Max. Dumping Height
7,150 mm
- -These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog.
- -The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
