HX300HD
Type
Medium Excavators
Operating Weight
30.6 ton
Emission
~TIER 2
Rated Power
260 hp / 2,200 rpm
Specifications
General
Bucket Capacity
2.1 m³
Operating Weight
30.6 ton
Rated Power
260 hp / 2200 rpm
Engine
Emission
~TIER 2
Max. Torque
115 kgf·m / 1,300 rpm
Engine Model
Hyundai HM8.3
Hydraulic System
Implement Circuit
350 kgf/cm²
Main Pumps Rated Flow
2x285 ℓ/min
Tank Capacity
Fuel Tank
500 ℓ
Hydraulic Tank
190 ℓ
Performance
Swing Speed
12.2 rpm
Travel Speed
6.1 km/h
Bucket Digging Force (ISO)
19,600 kgf
Arm Digging Force (ISO)
13,900 kgf
Max. Gradeability
35 deg
Max. Traction Force
27,400 kgf
Dimensions
Overall Width
3,400 mm
Overall Height
3,130 mm
Overall Length
10,700 mm
Ground Clearance
500 mm
Tail Swing Radius
3,350 mm
Tumbler Distance
4,030 mm
Operating Range
Arm Length
3,050 mm
Boom Length
6,250 mm
Min. Swing Radius
4,270 mm
Max. Digging Depth
7,330 mm
Max. Digging Reach
10,800 mm
Max. Digging Height
10,200 mm
Max. Dumping Height
7,150 mm
- -These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog.
- -The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
