HX350FC
Type
Others
Operating Weight
37.8 ton
Emission
TIER 3
Rated Power
280 hp / 2,200 rpm
Specifications
General
Operating Weight
37.8 ton
Rated Power
280 hp / 2200 rpm
Engine
Emission
TIER 3
Max. Torque
138.3 kgf·m / 1,500 rpm
Engine Model
CUMMINS / QSC
Hydraulic System
Type
Others
Implement Circuit
350 kgf/cm²
Main Pumps Rated Flow
2x297.5 ℓ/min
Tank Capacity
Fuel Tank
600 ℓ
Hydraulic Tank
210 ℓ
Performance
Swing Speed
10.2 rpm
Travel Speed
6.4 km/h
Max. Gradeability
35 deg
Max. Traction Force
27,400 kgf
Dimensions
Overall Width
3,470 mm
Overall Height
3,440 mm
Overall Length
11,200 mm
Ground Clearance
800 mm
Tail Swing Radius
3,510 mm
Tumbler Distance
4,030 mm
Operating Range
Arm Length
3,200 mm
Boom Length
6,450 mm
Min. Swing Radius
4,360 mm
Max. Digging Depth
3,620 mm
Max. Digging Reach
9,420 mm
Max. Digging Height
11,000 mm
Max. Dumping Height
7,260 mm
- -These specifications are based on the "standard specifications" or "with certain optional equipment." For more detailed information, please refer to the product catalog.
- -The above specifications are subject to change without notice for quality improvement, and the illustrations and photos on this page may differ slightly from the actual product in terms of color.
